FREQUENCY CONVERTER REOVIB MFS 268 HP-HC2

High-power version of the REOVIB MFS 268 frequency-control device, can be used for mains voltages of 400 V with max. 8 or 16 A output current and for mains voltages of 230 V with max. 12, 16, 32 A output current. Available as IP20 versions for installation in control cabinets and also as IP54 standalone units for 230 V and 12/16 A. We are also delighted to offer you a suitable control cabinet system with client specific requirements. Special designs of the REOVIB MFS 268 HP can also be implemented if required.

• Independant of the mains input frequency
• Able to automatically determine the resonant frequency of the vibratory conveyor system (with additional vibration amplitude sensor) and regulate the vibration amplitude and maintain a constant feedrate irrespective of load or changes in the mechanical system
• Field bus interfaces: ProfiNet, EtherNet/IP, EtherCAT, CAN-Bus, ProfiBus, DeviceNet
• Available with UL/CSA approval depending on the type (Optional)
• Conveyor frequencies adjustable between 5…300 Hz
• Mains voltage compensation with constant vibration amplitude
• All settings can be made using the integrated display
• Sinusoidal output current
• Can be used on 230 V or 400 V mains input
• User settings can be stored
• Fill level/overflow control
• Versions available in various protection classes and connector options
• MFS 269 HP is availble with AC output signal for use with permanent-magnet armature.
