EMC-Filter CNW 107.3/690
High-current mains filters (3 lines)
完整的目录
下载我们丰富的产品目录，发现更多REO产品
Data sheet
All data and configurations can be found in our product data sheet.
Certifications
EMC-Filter CNW 107.3/690
High-current mains filters (3 lines)
Description
The EMC filter is specifically for the suppression of high-current applications in wind energy and industrial applications designed. This filter series is for the voltage levels of 480V and 690V constructed.The filter can be delivered in various casing versions. So it can be adapted to different environmental conditions.
There are also versions for offshore applications possible.
Advantages
- specifically desiged for high performances
- suitable for offshore applications
- compact design
- good heat dissipation
- rail connector
- fast installation
Typical applications
The EMC filter is specifically for the suppression of high-current applications in wind energy and industrial applications designed.
Technical specifications
- Conforming to: VDE 0565-3 / IEC 950 / UL 1283
- Test voltage: L-N 2100 V,DC 1s, L/N-PE 2700 V,DC 1s
- Overload: 1,5 x I 1 min/h
- Climatic category: DIN IEC 68 Teil 1 25/085/21
Dimensions in mm
Hier drunter ist das Bildelement (Dieser Text ist unsichtbar.)
